介紹：
CUMMINS康明斯的零件手冊機型匯總
| B3.3/QSB3.3 | 3.3 | 4 | 60-110 | 機械式/全電控 | Tier 2/Tier 3 |
| B3.9 | 3.9 | 4 | 110-125 | 機械式 | Tier 2 |
| B4.5/QSB4.5 | 4.5 | 4 | 80-160 | 機械式/全電控 | Tier 2/Tier 3 |
| B5.9 | 5.9 | 6 | 150-178 | 機械式 | Tier 2 |
| QSB6.7 | 6.7 | 6 | 133-220 | 全電控 | Tier 3/Tier 4 |
| C8.3/QSC8.3 | 8.3 | 6 | 190-309 | 機械式/全電控 | Tier 2/Tier 3 |
| QSL9 | 8.9 | 6 | 280-365 | 全電控 | Tier 3 |
| M11/QSM11 | 11 | 6 | 290-400 | 機械式/全電控 | Tier 2/Tier 3 |
| QSX15 | 15 | 6 | 450-600 | 全電控 | Tier 2/Tier 3 |
| B3.3-85 | 85 @ 2600RPM | 292 @ 1600RPM |
| B3.3-85 | 85 @ 2600RPM | 292 @ 1600RPM |
| B3.3-80 | 80 @ 2200RPM | 292 @ 1600RPM |
| B3.3-80 | 80 @ 2200RPM | 292 @ 1600RPM |
| B3.3-65 | 65 @ 2600RPM | 214 @ 1600RPM |
| B3.3-60 | 60 @ 2200RPM | 214 @ 1600RPM |
| QSB3.3-80 | 80 @ 2200RPM | 372 @ 1400RPM |
| QSB3.3-85 | 85 @ 2600RPM | 372 @ 1400RPM |
| QSB3.3-99 | 99 @ 2200RPM | 412 @ 1400RPM |
| QSB3.3-99 | 99 @ 2600RPM | 412 @ 1400RPM |
| QSB3.3-110 | 110 @ 2400RPM | 412 @ 1400RPM |
| B3.9-125C | 125 @ 2200 | 481 @ 1500 |
| B3.9-110C | 110 @ 2200 | 468 @ 1500 |
| B3.9-125 | 110 @ 2200 | 475 @ 1500 |
| B3.9-110 | 110 @ 2200 | 450 @ 1500 |
| B3.9-95 | 95 @ 2200 | 384 @ 1500 |
| B5.9-200 | 200 @ 2500 | 804 @ 1500 |
| B5.9-185 | 185 @ 2500 | 746 @ 1500 |
| B5.9-174 | 174 @ 2500 | 621 @ 1500 |
| B5.9-165 | 165 @ 2500 | 597 @ 1600 |
| B5.9-152 | 152 @ 2500 | 561 @ 1600 |
| B5.9-115 | 115 @ 2200 | 424 @ 1600 |
| C8.3-300 | 300 @ 2200 | 1248 @ 1600 |
| C8.3-260 | 275 @ 2000 | 1119 @ 1500 |
| C8.3-260 | 260 @ 2200 | 1119 @ 1500 |
| C8.3-240 | 255 @ 2000 | 1017 @ 1500 |
| C8.3-240 | 240 @ 2200 | 1017 @ 1500 |
| C8.3-230 | 230 @ 2200 | 990 @ 1500 |
| C8.3-215 | 215 @ 2500 | 871 @ 1500 |
| C8.3-205 | 205 @ 2200 | 823 @ 1500 |
| C8.3-190 | 200 @ 2000 | 800 @ 1500 |
| C8.3-190 | 190 @ 2200 | 800 @ 1500 |
| 6L9.3T 220 | 220(162) @ 2200 | 890 @ 1400 |
| 6L9.3T 220 | 220(162) @ 2000 | 980 @ 1300 |
| 6L9.3TAA 220 | 220(162) @ 2200 | 940 @ 1400 |
| M11-350 | 350 @ 2100 | 1559 @ 1300 |
| M11-335 | 335 @ 1800 | 1458 @ 1300 |
| M11-330 | 330 @ 2100 | 1458 @ 1300 |
| M11-320 | 320 @ 2000 | 1234 @ 1300 |
| M11-315 | 315 @ 1800 | 1437 @ 1300 |
| M11-310 | 310 @ 2100 | 1424 @ 1300 |
| M11-300 | 300 @ 2100 | 1424 @ 1300 |
| M11-290 | 290 @ 2100 | 1329 @ 1300 |
| M11-280 | 280 @ 2100 | 1288 @ 1300 |
| M11-275 | 275 @ 1800 | 1288 @ 1300 |
| M11-270 | 270 @ 2100 | 1288 @ 1300 |
| M11-270 | 270 @ 1000 | 1248 @ 1300 |
| M11-265 | 265 @ 1700 | 1220 @ 1300 |
| M11-250 | 250 @ 2100 | 1146 @ 1300 |
| M11-245 | 245 @ 2100 | 1017 @ 1800 |
| M11-245 | 245 @ 2000 | 1058 @ 1300 |
| M11-245 | 245 @ 1800 | 1166 @ 1300 |
| M11-225 | 225 @ 2100 | 1031 @ 1300 |
| QSB3.3 | 80 @ 2200 | 372 @ 1400 |
| QSB3.3 | 85 @ 2600 | 372 @ 1400 |
| QSB3.3 | 99 @ 2200 | 412 @ 1400 |
| QSB3.3 | 99 @ 2600 | 412 @ 1400 |
| QSB3.3 | 110 @ 2400 | 412 @ 1400 |
| QSB4.5 | 110 @ 2200 | 489 @ 1500 |
| QSB4.5 | 130 @ 2300 | 511 @ 1500 |
| QSB4.5 | 148 @ 2300 | 598 @ 1500 |
| QSB4.5 | 160 @ 2200 | 622 @ 1500 |
| QSB4.5 | 170 @ 2500 | 622 @ 1500 |
| QSB6.7 | 133 @ 2000 | 431 @ 1450 |
| QSB6.7 | 155 @ 2200 | 618 @ 1500 |
| QSB6.7 | 173 @ 2200 | 800 @ 1400 |
| QSB6.7 | 190 @ 2200 | 929 @ 1400 |
| QSB6.7 | 215 @ 2200 | 888 @ 1500 |
| QSB6.7 | 220 @ 2200 | 945 @ 1500 |
| QSB6.7 | 240 @ 2500 | 987 @ 1500 |
| QSB6.7 | 260 @ 2500 | 990 @ 1500 |
| QSC8.3-340* | 340 @ 2200 | 1424 @ 1400 |
| QSC8.3-320* | 320 @ 2200 | 1356 @ 1400 |
| QSC8.3-300 | 300 @ 2200 | 1356 @ 1400 |
| QSC8.3-280 | 280 @ 2200 | 1268 @ 1400 |
| QSC8.3-260 | 260 @ 2200 | 1178 @ 1400 |
| QSC8.3-240 | 240 @ 2200 | 1085 @ 1400 |
| QSM11-400 | 400 @ 2100 | 1898 @ 1400 |
| QSM11-375 | 375 @ 2100 | 1898 @ 1400 |
| QSM11-350 | 350 @ 2100 | 1775 @ 1400 |
| QSM11-335 | 335 @ 2100 | 1673 @ 1400 |
| QSM11-300 | 300 @ 2100 | 1424 @ 1400 |
| QSM11-290 | 290 @ 2100 | 1478 @ 1400 |
| QSX15-600 *** | 600 @ 2100 | 2780 @ 1400 |
| QSX15-600 | 600 @ 1800 | 2780 @ 1400 |
| QSX15-440 | 440 @ 2000 | 2237 @ 1300 |
| QSX15-425*** | 425 @ 2100 | 1949 @ 1400 |
| QSX15-425*** | 425 @ 2100 | 1948 @ 1400 |
| QSX15-375 | 375 @ 2100 | 1871 @ 1400 |
| QSX15-360*** | 360 @ 2100 | 1648 @ 1400 |
